We are the Authorised Sales & Service Dealer for Escorts DG Sets. Power Teck Solutions offers a wide range of power engineering products such as diesel generator sets and portable generators, along with electrical and turnkey engineering projects. Our technical know-how ensures high quality, on-time delivery, and value-added services. We help customers across different product ranges, delivering exceptional after-sales support, low maintenance costs, and user‑friendly equipment.
| DG Set Model | UNIT | EKL7.5-IV | EKL10-IV | EKL15-IV | EKL20-IV(3) | EKL20A-IV | |
|---|---|---|---|---|---|---|---|
| Power Rating | kVA/kWe | 7.5 | 10 | 15 | 15/20 | 15/20 | 25 |
| Canopy Size | LxWxH (mm) | 1700 X 900 X 1150 | 1700 X 900 X 1150 | 1700 X 900 X 1150 | 1950 X 1000 X 1300 | 1950 X 1000 X 1300 | 2250 X 1030 X 1470 |
| Battery | AH | 88 | 88 | 88 | 110 | 88 | 110 |
| Starting system | 12 Volts DC | 12 Volts DC | 12 Volts DC | 12 Volts DC | 12 Volts DC | 12 Volts DC | |
| Weight | Kg | 500 | 500 | 540 | 550 | 570 | 650 |
| Fuel tank capacity | Ltrs | 100 | 100 | 100 | 120 | 120 | 130 |
| Engine Model | G12-IV | G12-IV | G15-IV | G20-IV | G20A-IV | G30-IV | |
| Engine Power | BHP | 14.8 | 14.8 | 19 | 24.2 | 24.2 | 42 |
| Rated Speed | RPM | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| No. of Cylinders | 2 | 2 | 2 | 3 | 2 | 3 | |
| Bore | mm | 95 | 95 | 95 | 95 | 98 | 98 |
| Stroke | mm | 110 | 110 | 110 | 110 | 122 | 122 |
| Total Displacement | cc | 1560 | 1560 | 1560 | 2340 | 1840 | 2760 |
| Lube Oil Sump Capacity | Ltrs | 5.5 | 5.5 | 5.5 | 6.5 | 5.5 | 6.5 |
| Aspiration | Natural aspirated / Turbocharged | Natural aspirated | Natural aspirated | Natural aspirated | Natural aspirated | Turbocharged | |
| Cooling system | Water Cooled | Water Cooled | Water Cooled | Water Cooled | Water Cooled | Water Cooled | |
| Flywheel Housing /Flywheel | SAE3/SAE10 | SAE3/SAE10 | SAE3/SAE10 | SAE3/SAE10 | SAE3/SAE10 | SAE3/SAE10 | |
| Fuel System | MICO Bosch – Inline Pump | MICO Bosch – Inline Pump | MICO Bosch – Inline Pump | MICO Bosch – Inline Pump | MICO Bosch – Inline Pump | MICO Bosch – CRS | |
| Emission Norms | CPCB IV+ Compliant | CPCB IV+ Compliant | CPCB IV+ Compliant | CPCB IV+ Compliant | CPCB IV+ Compliant | CPCB IV+ Compliant | |
| Type/Make | Brushless,H class Insulation/Stamford or Equivalent | Brushless,H class Insulation/Stamford or Equivalent | Brushless,H class Insulation/Stamford or Equivalent | Brushless,H class Insulation/Stamford or Equivalent | Brushless,H class Insulation/Stamford or Equivalent | Brushless,H class Insulation/Stamford or Equivalent | |
| Frequency | Hz | 50 | 50 | 50 | 50 | 50 | 50 |
| Voltage | Volts | 230/415 | 230/415 | 230/415 | 230/415 | 230/415 | 230/415 |
| DG Set Model | UNIT | EKL25-IV | EKL30-IV | EKL35-IV | EKL40-IV | EKL45-IV | EKL50-IV | EKL62.5-IV |
|---|---|---|---|---|---|---|---|---|
| Power Rating | kVA/kWe | 30 | 35 | 40 | 45 | 50 | 60 | |
| Canopy Size | LxWxH (mm) | 2250 X 1030 X 1470 | 2250 X 1030 X 1470 | 2250 X 1030 X 1470 | 2250 X 1030 X 1470 | 2500 X 1050 X 1500 | 2500 X 1050 X 1500 | |
| Battery | AH | 110 | 110 | 110 | 110 | 110 | 110 | |
| Starting system | 12 Volts DC | 12 Volts DC | 12 Volts DC | 12 Volts DC | 12 Volts DC | 12 Volts DC | ||
| Weight | Kg | 670 | 700 | 720 | 750 | 800 | 900 | |
| Fuel tank capacity | Ltrs | 130 | 130 | 130 | 130 | 130 | 130 | |
| Engine Model | G30-IV | G40-IV | G40-IV | G40-IV | G62.5 | G62.5 | ||
| Engine Power | BHP | 42 | 57.6 | 57.6 | 57.6 | 72.7 | 72.7 | |
| Rated Speed | RPM | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | |
| No. of Cylinders | 3 | 3 | 3 | 3 | 4 | 4 | ||
| Bore | mm | 98 | 98 | 98 | 98 | 98 | 98 | |
| Stroke | mm | 122 | 122 | 122 | 122 | 122 | 122 | |
| Total Displacement | cc | 2760 | 2760 | 2760 | 2760 | 3680 | 3680 | |
| Lube Oil Sump Capacity | Ltrs | 6.5 | 6.5 | 6.5 | 6.5 | 11 | 11 | |
| Aspiration | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Turbocharged | ||
| Cooling system | Water Cooled | Water Cooled | Water Cooled | Water Cooled | Water Cooled | Water Cooled | ||
| Flywheel Housing /Flywheel | SAE3/SAE10 | SAE3/SAE10 | SAE3/SAE10 | SAE3/SAE10 | SAE3/SAE10 | SAE3/SAE10 | ||
| Fuel System | MICO Bosch – CRS | MICO Bosch – CRS | MICO Bosch – CRS | MICO Bosch – CRS | MICO Bosch – CRS | MICO Bosch – CRS | ||
| Emission Norms | CPCB IV+ Compliant | CPCB IV+ Compliant | CPCB IV+ Compliant | CPCB IV+ Compliant | CPCB IV+ Compliant | CPCB IV+ Compliant | ||
| Type/Make | Brushless,H class Insulation/Stamford or Equivalent | Brushless,H class Insulation/Stamford or Equivalent | Brushless,H class Insulation/Stamford or Equivalent | Brushless,H class Insulation/Stamford or Equivalent | Brushless,H class Insulation/Stamford or Equivalent | Brushless,H class Insulation/Stamford or Equivalent | ||
| Frequency | Hz | 50 | 50 | 50 | 50 | 50 | 50 | |
| Voltage | Volts | 230/415 | 230/415 | 230/415 | 230/415 | 230/415 | 230/415 |
| Specification | 75/82.5 kVA | 100 kVA | 125 kVA |
|---|---|---|---|
| Power Rating (kVA/kWe) | 75/60 | 100/80 | 125/100 |
| Electric Power | 60 | 80 | 100 |
| Rated Current | 104/115 | 139 | 174 |
| DG Size (L) | 2850 | 3000 | 3200 |
| DG Size (W) | 1300 | 1300 | 1300 |
| DG Size (H Including Base) | 1625 | 1610 | 1625 |
| DG Weight approx. | 1417 | 1900 | 2050 |
| Fuel Tank Capacity | 190 | 200 | 200 |
| Battery Capacity | 90 | 90 | 90 |
| System DC Voltage | 12 | 12 | 12 |
| Engine Model | H4G4DE82 | H4G4DE100 | H6G4DE125 |
| Engine Rated kW/Engine Rated HP | 78 / 104 | 92 / 122 | 116 / 154 |
| Aspiration | TCIC | TCIC | TCIC |
| No. of cylinders & configuration | 4, In line | 4, In line | 6, In line |
| Bore x Stroke | 104 x 118 | 104 x 118 | 104 x 118 |
| Displacement | 4 | 4 | 6 |
| Compression ratio | 16.5 ± 0.5 : 1 | 16.5 ± 0.5 : 1 | 16.5 ± 0.5 : 1 |
| Fuel Consumption (75% Load) | 14.7 | 17.0 | 22.1 |
| Lube Oil Capacity approx. | 12 | 12 | 18 |
| Coolant Capacity approx. | 18 | 20 | 22 |
| Governing Class | A0 | A0 | A0 |
| Governer Used | Electronic | Electronic | Electronic |
| Oil Change Period | 1000 h | 1000 h | 1000 h |
| Lube Oil specification | Gulf 10W30 CK4 | Gulf 10W30 CK4 | Gulf 10W30 CK4 |
| Specification | 160 kVA | 180 kVA | 200 kVA | 250 kVA |
|---|---|---|---|---|
| Power Rating (kVA/kWe) | 160/128 | 180/144 | 200/160 | 250/200 |
| Electric Power | 128 | 144 | 160 | 200 |
| Rated Current | 223 | 250 | 278 | 346 |
| DG Size (L) | 3600 | 3800 | 4700 | 4700 |
| DG Size (W) | 1400 | 1400 | 1600 | 1600 |
| DG Size (H Including Base) | 1750 | 1710 | 2020 | 2020 |
| DG Weight approx. | 2210 | 2280 | 4500 | 4500 |
| Fuel Tank Capacity | 250 | 250 | 340 | 340 |
| Battery Capacity | 110 | 110 | 110 | 110 |
| System DC Voltage | 12 | 12 | 24 | 24 |
| Engine Model | H6G4DE160 | H6G4DE180 | A6G4DE200 | A6G4DE250 |
| Engine Rated kW/HP | 147 / 197 | 165 / 220 | 178 / 237 | 223 / 303 |
| Aspiration | TCIC | TCIC | TCIC | TCIC |
| No. of cylinders & configuration | 6, In line | 6, In line | 6, In line | 6, In line |
| Bore x Stroke | 104 x 118 | 104 x 118 | 112 x 135 | 112 x 135 |
| Displacement | 6 | 6 | 7.98 | 7.98 |
| Compression ratio | 16.5 ± 0.5 : 1 | 16.5 ± 0.5 : 1 | 17.5 ± 0.5 : 1 | 17.5 ± 0.5 : 1 |
| Fuel Consumption (75% Load) | 27.5 | 30.4 | 32.0 | 39.3 |
| Lube Oil Capacity approx. | 18 | 18 | 28 | 28 |
| Coolant Capacity approx. | 24 | 24 | 55 | 55 |
| Governing Class | A0 | A0 | A0 | A0 |
| Governer Used | Electronic | Electronic | Electronic | Electronic |
| Oil Change Period | 1000 h | 1000 h | 1500 h | 1500 h |
| Lube Oil specification | Gulf 10W30 CK4 | Gulf 10W30 CK4 | Gulf 10W30 CK4 | Gulf 10W30 CK4 |
Authorised Dealer for Escorts Diesel Generators & Honda Petrol Generators
Delivering reliable, efficient power solutions across Tamil Nadu.
